GT-FM24 magnesium oxide powder filling machine

GT-FM24 magnesium oxide powder filling machine

Item No.:GT-FM24
station: 24 station
filling length: 300-3000mm
diameter:<Φ12.7mm
INQUIRY

★Description
FM filling machine suitable for fill tubular heaters in long length, different diameter. The heaters fill by FM filling machines are in high density, which can up to 2.3g/cm3 depend to the diameter, MGO powder, filling speed. There are double guide tube filling machine and three guide tube filling machine in FM filling machine. FM filling machine can make in different length according to order (1000-8000mm). One time can fill 1-6 different diameters on one machine according to order.
★Main details
1.Filling station: 6-48 stations according to order and diameter.
2.Filling diameter: with one diameter on the machine according to order.
3.Filling length: 300-max length according to order.
4.Filling speed: 150-500mm / min adjustable.
5.Power supply: AC380V,50HZ.
6.Size of machine: 1700*1000mm*(max length*2+2000)mm (L*W*H)

model

diameter/length to fill

control

vibration

power

air supply

Size(H*L*W)

weight

GT-FM24 PLC - (6-48) station double three guide tubes

Φ7.5-Φ28.5mm

300mm-8000mm

PLC+touch screen
