MGO Heater Filling Equipment

GT-FM12 Zhaoqing Greater heater MGO powder filling machine

station: 12 stations
filling length: 300-8000 mm according to order
filing density: up to 2.35g/cm3
Air supply: 0.6MPa clean compressed air
INQUIRY

★Description

FM filling machine suitable for fill tubular heaters in long length, different diameter. The heaters fill by FM filling machines are in high density, which can up to 2.3g/cm3 depend to the diameter, MGO powder, filling speed. There are double guide tube filling machine and three guide tube filling machine in FM filling machine. FM filling machine can make in different length according to order (1000-8000mm). One time can fill 1-6 different diameters on one machine according to order.

★Main details
1. Filling station: 6-48 stations according to order and diameter.

2. Filling diameter: with one diameter on the machine according to order.

3. Filling length: 300-max length according to order.

4. Filling speed: 150-500mm / min adjustable.

5. Power supply: AC380V,50HZ.

6. Size of machine: 1700*1000mm*(max length*2+2000)mm (L*W*H)
